5.4.1 Setup & Programming the Operating Parameters in the Telguard
When the Telguard is received from the factory and is powered up for the first time, it is immediately
ready for registration, provided the default settings are what you want. The STC LED #2 will flash to
indicate any failure conditions. The MODE LED #3 will be on and the STC 1 and STC 2 relays will be
tripped. If changes are required to the default settings, the Telguard can be programmed using a line-
mans butt-set connected to T & R Test Points or a POTS phone connected to J7 (black connector where
the C/C is normally connected).
5.4.1.1 Command Key Sequences for Pots Programming
Key Sequence Description
# * Enters the programming Mode
*
Exits programming and stores changes
TO PROGRAM THE TELGUARD
A. Put the line-mans butt-set in talk mode or pick up the POTS phone,
B. Connect power to the Telguard, when ready for programming you will hear 2 beeps
C. Press #, *, this will put the Telguard into a Master Access programming mode, 2 beeps.
D. Enter changes required
The syntax for programming a specific memory location is as follows:
MEMORY LOCATION (3-digits), will respond with 2 beeps, then VALUE, will respond
with 2 beeps.
E. Then press *, you will hear 2 beeps then hang up. This saves the change and exits the programming
mode.
EXAMPLE
To change the Telguard factory default for STC 1 Trip Output reporting from only LFC to include all
system trouble conditions the installer would power down the Telguard, connect a butt-set to the
T & R test points, reconnect power.
Next press #, * the unit will generate 2 beeps.
Then press 850, the Telguard will respond with 2 beeps, then press 31, the Telguard will respond with 2
beeps, then press *, you will hear 2 beeps then hang up. (this will change STC 1 trip output to report all
system trouble conditions) The Telguard will automatically transmit a message to update the Telular
Communication Center.
