5.4.4 Re-connect telco line (RJ-31x Jack) to Telguard Jack J6 (GRAY Connector)
Plug the modular jack of the cable from RJ-31x jack in the premise to J6 (gray) on the Telguard.
5.5 STEP 5: CONNECT SUPERVISORY TRIP OUTPUTS
Connect and test the supervisory trip outputs to the C/C.
NOTE: Activation of a local alarm or strobe light may be desirable when a trip is declared. The STC trip output can be
used directly to activate a local signaling device, provided that the trip output is not needed to trip the host
control/communicator at the same time. If both a local signal and a control trip input are required, then external relays
are needed to provide additional uncommitted contacts.
UL Listed installation of the TG-4 will at a minimum have the trip output (STC2) to the host C/C to indicate low A/C
(ACFC) and low battery (LBC) conditions.
5.5.1 Decide on a STC Trip Output Strategy
The Telguard provides the host C/C with two supervisory trip outputs for reporting a Telguard system trouble
code to the central station. The supervisory trip outputs are programmable via a touch-tone telephone or
buttset to suit various installation requirements. The programming options for these supervisory trip outputs
can be any combination of the following:
a. Always Off: Disables all relay supervisory functions.
b. ACFC: Trips 2 hours after loss of AC power. Restores 60 seconds after AC power is restored.
c. LBC: Trips within 60 seconds on low battery condition. Restores when battery voltage ≥ 12.1 vdc.
d. LFC: Trips 30/60-sec. on Telco line fault condition. Restores 30/60 seconds after Telco line restores.
e. NSC: Trips 30/60-sec. on no service condition due to loss of RF signal strength. Restores 30/60 seconds
after RF signal strength is available.
f. RFC: Trips on radio failure to communicate with the Telular Communication Center.
5.5.2 Check Telguard Supervisory Trip to C/C
After you have connected the STC trip outputs, check to be sure that they operate correctly.
5.5.2.1 Reprogram C/C to Send Proper Code
Reprogram C/C, if necessary, to send proper alarm code when tripped by the Telguard’s supervisory output.
Program zone restoral as desired.
5.5.2.2 Check Proper Operation of Telguard Supervisory Output
Check for proper operation of each programmed supervisory output by causing it to trip the C/C and be sure
the proper LED illuminates and that the proper trouble code is reported to the central station. Skip the testing
of any supervisory functions that have not been enabled. Note that the yellow MODE LED #3 starts to flash
when the C/C goes off-hook to report the alarm signal over cellular.
• Low Battery Condition (LBC)
: Disconnect the battery and during the next 60 seconds check to see that
the STC LED #2 flashes 2 times indicating that the battery is missing. Check to see that the C/C
transmits the STC trouble code (over cellular) to the central station. Reconnect the battery and check
during the next 60 seconds to see that the STC LED #2 goes off, indicating the missing battery condition
has been restored.
• Line Fault Condition (LFC):
Disconnect J/J cable at RJ-11. Check to see that the STC LED #2 flashes
3 times in 30/60 seconds and the C/C transmits the STC trouble code (over cellular) to the central station
indicating the incoming telco line is disconnected. Reconnect J/J cable and check to see that the STC
LED #2 goes off in 30/60-seconds indicating telco line restored.
