A2.2 COMPATIBLE CONTROL COMMUNICATORS
Any UL Listed Control Communicator that supports the listed formats (Contact ID, Pulse, Radionics, SIA2
and DMP) are compatible and may be used with TG-4. The installer should verify the complete
compatibility at the time installation.
A3.0 Detailed Specifications
A3.1 DIALER TO INTERFACE ELECTRONICS
The patented integrated interface by Telular, Inc. allows digital dialers to dial into the cellular radio network.
• Line voltage: -26 vdc into standard telephone device when on-hook.
• Dial tone: Precision 350 + 440Hz +/- 1%. 10 digits dial out capability.
• Mode: Loop start only. 25mA +/- 10% off-hook.
• Protected by U.S. Patents: 4,658,096; 4,775,997; 4,922,517; 4,737,975; 4,868,519; 5,134,644.
A3.2 POWER
• Maximum AC current draw: 100mA
• Battery Supply:
• Maximum full charge DC voltage = 13.8V +/- 0.2V.
• Battery charging system: Constant current, Electronic short circuit protection
• Maximum charging current of 240ma
• Transformer Supplied: 12 VAC 10VA, UL, plug-in; acceptable transformers:
• Basler Electronics part number: S189480032
• GlobTek part number: WA1E800J00-N-GTGTAB
• Tri-Mag part number: WTD-1208-C
A3.3 DIGITAL CELLULAR RADIO
The Telguard TG-4 radio supports GSM/GPRS cellular protocol. It is equipped with an integrated radio transceiver
conforming to all the requirements of the GSM Phase 2+ tests specified in GSM 11.10. The TG-4 transceiver is FCC
compliant, meeting all of the requirements of Part 24 and SAR testing. It is also compliant to the PCTRB NAPRD03
requirements.
• Frequency range: GSM 850/1900MHz,
1. 824MHz-849MHz
2. 1850MHz-1909MHz
• Antenna Port: TNC connector (female), 50-ohm
• Receiver Sensitivity: -102 dBm
• Transmit Power: EGSM 850MHz: Class 4 (2 watts)
GSM 1900MHz: Class 1 (1 watt)
• FCC ID: MTFTG5112597
• FCC Registration: MTFAL03BTG4G0001
• Supplied Antenna: Dipole
• Physical Size: 9.5"H x 4.5"W x 1.75"D.
• Shipping weight: 5 lbs.
• Operating Environment: 0
°
C to +49
°
C; 0 - 85% humidity (non-condensing).
A3.4 TELCO INTERFACE
• Ringer equivalence: 0.3B REN
