HE910 Hardware User Guide
1VV0300925 Rev. 32 Page 90 of 111 2019-11-25
ADC Converter
14.8.1. Description
The HE910 is provided by one AD converter. It is able to read a voltage level in the range
of 0÷1.2 volts applied on the ADC pin input, store and convert it into 10 bit word.
The following table is showing the ADC characteristics:
The input line is named as ADC_IN1 and it is available on Pad B1
14.8.2. Using ADC Converter
An AT command is available to use the ADC function
The command is AT#ADC=1,2
The read value is expressed in mV
Refer to SW User Guide or AT Commands Reference Guide for the full description of this
function.
