HE910 Hardware User Guide
1VV0300925 Rev. 32 Page 91 of 111 2019-11-25
15. MOUNTING THE HE910 ON THE APPLICATION
General
The HE910 modules have been designed in order to be compliant with a standard lead-
free SMT process.
Module finishing & dimensions
Figure 15-1 Module finishing
Pin B1
Dimensions in mm
Bottom view
Lead-free Alloy:
Surface finishing Ni/Au for all solder pads
