Telit Wireless Solutions WE866E4-P User Manual

WE866E4-P Module Hardware User Guide
1VV0301487 Rev. 1.2 23 2018-07-27
PRELIMINAR
Y
Chapter 6 RF Section
• RF Variants, page 23
• TX Output Power, page 24
• RX Sensitivity, page 26
• Wi-Fi Antenna Requirements, page 27
• BlueTooth Antenna Requirements, page 29
6.1 RF Variants
6.1.1 Wi-Fi
Table 9, page 23 describes the Wi-Fi RF Frequency band.
6.1.2 Bluetooth
Table 10, page 23 describes the Bluetooth RF Frequency band.
Table 9 Wi-Fi Frequency Band
RF Frequency Channel Range Units
2.4GHz RF Frequency range
Center channel frequency
at 5MHz spacing
2.412 ≤ Fc ≤
2.484
GHz
5GHz RF Frequency range
Center channel frequency
at 5MHz spacing
4.9 ≤ Fc ≤ 5.925 GHz
Table 10 Wi-Fi Frequency Band
RF Frequency Channel Range Units
RF Frequency range
Fc=2402 + k × 2 MHz,
where k = 0, ..., 39
2.4 ≤ F ≤ 2.4835. GHz
