WE866E4-P Module Hardware User Guide
1VV0301487 Rev. 1.2 25 2018-07-27
PRELIMINAR
Y
6.2.1.2 For 5GHz
Table 12, page 25 lists the Wi-Fi RF Frequency Transmission for 5GHz.
Table 12 Wi-Fi RF Frequency Transmission for 5GHZ
Standard Modulation Data rates
2.4 GHz: Transmit power with IEEE 802.11 EVM and spectral mask
compliance at balun output at 25 ° Degrees
Index
802.11b/g 802.11n 20 MHz 802.11n 40 MHz Unit
Typ Typ Typ
802.11b
BPSK 6 Mbps 16 NA NA dBm
BPSK 9 Mbps 16 NA NA dBm
QPSK 12 Mbps 16 NA NA dBm
QPSK 18 Mbps 16 NA NA dBm
16 QAM 24 Mbps 16 NA NA dBm
16 QAM 36 Mbps 14 NA NA dBm
64 QAM 48 Mbps 13 NA NA dBm
64 QAM 54 Mbps 13 NA NA dBm
802.11g
BPSK 6 Mbps 19 NA NA dBm
BPSK 9 Mbps 19 NA NA dBm
QPSK 12 Mbps 19 NA NA dBm
QPSK 18 Mbps 18 NA NA dBm
16 QAM 24 Mbps 18 NA NA dBm
16 QAM 36 Mbps 18 NA NA dBm
64 QAM 48 Mbps 18 NA NA dBm
64 QAM 54 Mbps 18 NA NA dBm
802.11n
BPSK MCS0 NA 16 15 dBm
QPSK MCS1 NA 16 15 dBm
QPSK MCS2 NA 15 14 dBm
16 QAM MCS3 NA 15 14 dBm
16 QAM MCS4 NA 14 13 dBm
64 QAM MCS5 NA 14 13 dBm
64 QAM MCS6 NA 13 12 dBm
64 QAM MCS7 NA 13 12 dBm
Note: The performance includes balun, but excludes external duplexer, filter and external switch loss.
