WE866E4-P Module Hardware User Guide
1VV0301487 Rev. 1.2 27 2018-07-27
PRELIMINAR
Y
6.3.2 Bluetooth
Table 16, page 27 lists the Bluetooth RX Sensitivity.
6.4 Wi-Fi Antenna Requirements
Special care must be taken during the design of the RF section on the application board.
CAUTION! : If The below recommendation is strictly not followed then RF performance
degradation and infringements of emission limits will occur
A 50Ω antenna is required with Telit’s WE866E4-P module interface features an SMA
connector for an external antenna, alternatively a chip or a printed antenna can be used.
If an integrated or printed antenna is used, it is recommended to place it at the edge of the
application board. Since the antenna impedance is required to be tuned to 50Ω.
It is recommended to foresee a PI matching network between the WE866E4-P module and
the antenna during first prototyping. If not, a series 0Ω-resistor can be used, leaving the two
shunt components unpopulated.
To meet Telit’s FCC certification standard, the antenna on the application board should
have a gain value equal/less then the one recommended by Telit.
Table 15 RX Sensitivity for 5GHZ
Standard Modulation Data rates
2.4 GHz: Transmit power with IEEE 802.11 EVM and spectral mask
compliance at balun output at 25 °
Index
802.11b/g 802.11n 20 MHz 802.11n 40 MHz Unit
Typ Typ Typ
802.11b
BPSK 6 Mbps -93 NA NA dBm
64 QAM 54 Mbps -75.5 NA NA dBm
802.11g
BPSK MCS0 NA -93 -90 dBm
64 QAM MCS7 NA -72.5 -69 dBm
Note: The performance includes balun, but excludes external duplexer, filter and external switch loss.
Table 16 Bluetooth RX Sensitivity
RX Characteristic Rate Min Type Max Units
RX Sensitivity 1Mbps <-= -70dBM -97 -99 dBm
Note: Measurement data is at chip output, 25°C, 1.8V IO.
