WE866E4-P Module Hardware User Guide
1VV0301487 Rev. 1.2 26 2018-07-27
PRELIMINAR
Y
6.2.2 Bluetooth
Table 13, page 26 lists the Bluetooth Transmission.
6.3 RX Sensitivity
6.3.1 Wi-Fi
6.3.1.1 For 2.4GHz
Table 14, page 26 lists the RX Sensitivity for 2.4GHz.
6.3.1.2 For 5GHz
Table 15, page 27 lists the RX Sensitivity for 5GHz.
Table 13 Bluetooth Transmission
TX Characteristic Rate Min Type Max Units
Max RF Output Power
LE 1M 1.5 4 4.3 dBm
LE 2M 1.5 4 4.2 dBm
Note:
1).Measurement data is at chip output, 25°C, 1.8V IO. 2).When Tx power higher than 4dBm, an external BPF is required for out of band emis-
sion. BPF spec is upon the external PA is selected.
Table 14 RX Sensitivity for 2.4GHZ
Standard Modulation Data rates
2.4 GHz: Transmit power with IEEE 802.11 EVM and spectral mask
compliance at balun output at 25 °Degrees
Index
802.11b/g 802.11n 20 MHz 802.11n 40 MHz Unit
Typ Typ Typ
802.11b
BPSK 1 Mbps 19 NA NA dBm
QPSK 2 Mbps 19 NA NA dBm
CCK 5.5 Mbps 19 NA NA dBm
CCK 11 Mbps 19 NA NA dBm
802.11g
BPSK 6 Mbps 19 NA NA dBm
BPSK 9 Mbps 19 NA NA dBm
Note: The performance includes balun, but excludes external duplexer, filter and external switch loss.
