Quick Manual v1.2 // FMC130
16
ELECTRICAL
CHARACTERISTICS
CHARACTERISTIC
DESCRIPTION
VALUE
SUPPLY VOLTAGE MIN. TYP. MAX. UNIT
Supply Voltage
(Recommended
Operating Conditions)
+10 +30 V
DIGITAL OUTPUT (OPEN DRAIN GRADE)
Drain current (Digital
Output OFF)
120 µA
Drain current
(Digital Output ON,
Recommended
Operating Conditions)
0.1 0.5 A
Static Drain-Source
resistance (Digital
Output ON)
400 600 mΩ
DIGITAL INPUT
Input resistance (DIN1) 47 kΩ
Input resistance (DIN2) 38.45 kΩ
Input resistance (DIN3) 150 kΩ
Input voltage
(Recommended
Operating Conditions)
0
Supply
voltage
V
Input Voltage threshold
(DIN1)
7.5 V
Input Voltage threshold
(DIN2)
2.5 V
Input Voltage threshold
(DIN3)
2.5 V
ANALOG INPUT
Input voltage
(Recommended
Operating Conditions),
Range 1
0 +10 V
Input resistance,
Range 1
38.45 kΩ
Measurement error on
12V, Range 1
0.9 %
Additional error on 12
V, Range 1
108 mV
Measurement error on
30 V, Range 1
0.33 %
Additional error on 30
V, Range 1
88 mV
