Teltonika RUT955 User Manual

RUT955 User‘s Manual
Teltonika Solutions
196
9.18.3 UPnP ACLs
ACLs specify which external ports may be redirected to which internal addresses and ports.
Field name
Explanation
1.
Comment
Add comment to this rule
2.
External ports
External ports which may be redirected
3.
Internal addresses
Internal address to be redirect to
4.
Internal ports
Internal ports to be redirect to
5.
Action
Allow or forbid UPNP service to open the specified port
9.18.4 Active UPnP Redirects
9.19 QoS
QoS (Quality of Service) is the idea that transmission rates, error rates, and other characteristics can be measured,
improved, and, to some extent, guaranteed in advance. QoS is of particular concern for the continuous transmission of
high-bandwidth video and multimedia information.
QoS can be improved with traffic shaping techniques such as packet, network traffic, and port prioritization.
Field name
Value
Explanation
1.
Interface
WAN/LAN/PPP
2.
Enable
Enable/Disable
Enable/disable settings

Teltonika RUT955 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB 2.0 ports quantity	1
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
2G standards	Edge
3G standards	DC-HSPA+, HSPA+, WCDMA
GSM bands supported	800, 850, 900, 1800, 1900 MHz
Antennas quantity	5
Security algorithms	IPSEC, SNMP, WEP, WPA, WPA2
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power
Housing material	Aluminum
Processor frequency	560 MHz
AC input voltage	100 - 240 V
Power source type	AC, DC
Power consumption (typical)	7 W
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	46 mm
Width	106 mm
Height	80 mm
Weight	280 g
