Teltonika RUT955 User Manual

RUT955 User‘s Manual
Teltonika Solutions
201
16.
Sender's email
address
sender@example.com
Specify your email address. Only shown when Action is Send email
17.
Recipient's
email address
recipient@example.com
Specify for whom you want to send email. Only shown when Action
is Send email
18.
Sim
Primary/ Secondary
Specify which one SIM card will be changed. Only shown when
Action is Change SIM Card
19.
Profile
Admin
Specify which profile will be set and used. Only shown when Action is
Change Profile
20.
Reboot after (s)
4
Device will reload after a specified time (in seconds). Only shown
when Action is Reboot
21.
Output
activated
10
Output will be activated for specified time (in seconds) , or while
exists.
22.
Output type
Digital OC output/ Relay
output
Specify output type, which will be activated, depending on output
time. Only shown when Action is Activate output
9.20.3 Output
9.20.3.1 Output Configuration
Field name
Sample
Explanation
1.
Open collector
output
Low level / High level
Choose what open collector output will be in active state
2.
Relay output
Contacts closed / Contacts open
Choose what relay output will be in active state
9.20.3.2 ON/OFF
Field name
Sample
Explanation
1.
Digital OC output
Turn on / Turn Off
Manually toggle Digital OC output

Teltonika RUT955 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB 2.0 ports quantity	1
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
2G standards	Edge
3G standards	DC-HSPA+, HSPA+, WCDMA
GSM bands supported	800, 850, 900, 1800, 1900 MHz
Antennas quantity	5
Security algorithms	IPSEC, SNMP, WEP, WPA, WPA2
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power
Housing material	Aluminum
Processor frequency	560 MHz
AC input voltage	100 - 240 V
Power source type	AC, DC
Power consumption (typical)	7 W
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	46 mm
Width	106 mm
Height	80 mm
Weight	280 g
