Teltonika RUT955 User Manual

RUT955 User‘s Manual
Teltonika Solutions
197
3.
Calculate overhead
Enable/Disable
Check to decrease upload and download ratio to prevent link
saturation
4.
Half-duplex
Enable/Disable
Check to enable data transmission in both direction on a single
carrier
5.
Download speed (kbit/s)
1024
Specify maximal download speed
6.
Upload speed (kbit/s)
128
Specify maximal upload speed
Field name
Explanation
1.
Target
Select target for which rule will be applied
2.
Source host
Select host from which data will be transmitted
3.
Destination host
Select host to which data will be transmitted
4.
Service
Select service for which rule will be applied
5.
Protocol
Select data transmission protocol
6.
Ports
Select which port will be used for transmission
7.
Number of bytes
Specify the maximal number of bytes for connection
9.20 Input/Output
9.20.1 Status
In this page you can review the current state of all router’s inputs and outputs.

Teltonika RUT955 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB 2.0 ports quantity	1
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
2G standards	Edge
3G standards	DC-HSPA+, HSPA+, WCDMA
GSM bands supported	800, 850, 900, 1800, 1900 MHz
Antennas quantity	5
Security algorithms	IPSEC, SNMP, WEP, WPA, WPA2
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power
Housing material	Aluminum
Processor frequency	560 MHz
AC input voltage	100 - 240 V
Power source type	AC, DC
Power consumption (typical)	7 W
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	46 mm
Width	106 mm
Height	80 mm
Weight	280 g
