Servicing
Page 19 of 24
Table1,InformationavailableontheUC8display.
Item
Unit
Abbreviation
Examples
Compressorsuctionlinepressure kPa SLP

Suctionlinepressure1034kPa
Evaporatingtemperature °C Et

Evaporatingtemperature12°C
Compressorsuctionline
temperature
°C SLt

Suctionlinetemperature18°C
Compressorsuctionsidesuperheat K SSH

Suctionsidesuperheat6K
Compressordischargelinepressure kPa dLP

Dischargelinepressure2447kPa
Condensingtemperature °C Ct

Condensingtemperature42°C
Compressordischargeline
temperature
°C dLt

Dischargelinetemperature70°C
Compressordischargeside
superheat
K dSH

Dischargesidesuperheat28K
Deicesensortemperature
(locatedonfinsoftheoutdoorcoil)
°C ICEt

Deicesensortemperature39°C
Capacity % CAP

Capacity100%
Expansionvalve1opening % EE1

Expansionvalve175%open
Expansionvalve2opening % EE2

Expansionvalve275%open



B
A
Ground
+12V DC
B
A
Ground
0-10V out #1
Ground
0-10V out #2
Ground
Water Pump
Sc (Ground)
Remote on/o
Ground
RS485 #1
RS485 #2
Display
Push Button
Internal Unit Controller (UC8)
