INSTRUCTION MANUAL
Before inserting the unit into the kitchen cabinet please unscrew the
original leveling feet
in white and screw the short leveling
feet
in black which are packed as the accessory to the front
bottom of the unit
Tighten the screws to fix the Bottom Mounting Bar which has
been xed on the bottom of the unit to the kitchen cabinet
For a rmly xing of the unit you can install an extra Top Mounting
Bar which is an accessory packed with the unit onto the topside of
the unit and screw it with the kitchen cabinet See right drawing
22L Control In Cabinet
Control Panel
Chrome Shelf
Front Louver
Adjustable Foot
Outside Canbinet
Handle
Door
Gasket
Single Zone
7
Bottles
33½”
(850mm)
34¼”
(870mm)
>20⁄”
(525mm)
>34¼”
(870mm)
5⁄”
(150mm)
6⁄”
To Next Page
