Temptech 56L - For 116 L Control in Cabinet; For 22 L;58 L;88 L;145 L Control in Cabinet


INSTRUCTION MANUAL
8.Screw the 8 screws of Upper Hnge and Bottom Hnge tghtly one by one.
Upper Hinge
Screws (4pcs)
Screws (4pcs)
Bottom Hinge

For 116L Control in Cabinet
•
The unit is with Left and Right door, it is no need to do door reversal.

For 22L/58L/88L/145L Control in Cabinet
Remarks:
•
To reverse the door from right hinge to left hinge, you need to get ready 2 new spare
parts: an Upper Left Hinge, and a Bottom Left Hinge.
•
All removed parts is suggested to be saved in case of door re-reversal.
1.Open the door, and loosen the 2 screws from Pvot Hnge of the Bottom Rght Hnge.
60
o
Min.
Bottom Right Hinge
Screw
Pivot Hinge
