Temptech 56L - 490 L -Tripe Zone Control In Cabinet


INSTRUCTION MANUAL

490L -Tripe Zone Control In Cabinet
Control Panel
(Upper Zone)
Triple Zone
170
Bottles
Long Shelf
Short Shelf
Front Louver
Outside Canbinet
Handle
Door
Gasket
Control Panel
(Mid & Lower Zone)
Foot
Adjustable
≥1835mm
(72 ¼”)
≥695mm
(27 ¼”)
1835mm
(72 ¼”)
655mm
(25 ¾”)
≥730mm
(28 ¾”)
680mm
26 ¾”
