INSTRUCTION MANUAL

For 270L/428L/468L/490L Control In Cabinet
IMPORTANT İNFORMATİON
We recommend that you secure the racks in place using adhesive tape to prevent causing damage when
handling the appliance and store all removed parts carefully.
1. Remove the Hole Cover and Upper Hnge Cover on top sde usng a at-head screwdrver.
Remove the Upper Hnge by unscrewng the Hex Head Srews (4pcs). Now carefully lft the Door
o the Bottom Hnge wth your assstant and gently set t asde. It s mportant to keep the
Hnge Washer
on the top of Bottom Hnge for re-nstallaton.
Hole Cover
Upper Hinge Cover
Hex Head Screw (4pcs)
Upper Hinge
Door
2.Move the Hnge Hole Cap (at the top of the door) from the left sde to the rght sde. Move the
Pvot Hnge (at the bottom of the door) from the rght to the left sde.
Pivot Hinge
Hinge Hole Cap
