Temsa TS 45 - Left Control Panel

32|TS 45
02 VEHICLE
INFORMATION
Rev. 00 / 10.02.14
2.3.1 Left Control Panel
Emergency Stop Switch
Switching off the Engine
by Emergency Stop Switch
Whentheswitchisactivated,the
enginestops,gearisengagedinto
neutralautomatically,hazardwarn-
ingashersstartashingandaisle
illuminationlamps,steplampslight
on.Noneofthebrakeunitsapart
fromthefootbrake,canbeusedtill
theswitchisreleased.
Reset the switch by switching it
backtoitsoriginalposition.
INFORMATION
Except for “Emergency Stop
Switch”, all switches except
“CentralLockingSwitch”and
“DimmerSwitch”statedinthis
section have LED’s on them
whichindicatethat function
isonoroff.
INFORMATION
Closing the red cover cap
pushestheswitchforwardand
holdsitinposition.
WARNING
Never use “emergency stop
switch”whiledriving.Useonly
whenthevehicleisstationary
andparkingbrakeisactivated.
Liftuptheredprotectioncapand
activatetheswitch.
ASR Disable Switch
DeactivatesASR(Ac-
celerationSlipRegu-
lation)System.
ENGINE
START
Start Switch
Runstheengine.
ACC Switch
Activatesanddeac-
tivates the battery
main switch. Push
the upper side to
switch for give en-
ergyfrombatteryto
electrical system. Push the lower
side to switch for deactivate the
batteryandstoptheengine.
ACC
OFF
IGNITION
