Rev. 00 / 10.02.14
WARNING
•
Do not exceed rated load
capacity of 660 pounds
(300 kg).
•
Inspect lid before use. Do
not use lift an unsafe condi-
tion exits or if unusual noise
or movement is noticed.
Contact authorized Temsa
Service.
•
Lift mechanism is to be used
by one wheelchair occupant
only. Do not overload lift.
•
Do not allow an untrained
person to operate lift.
•
Lock wheelchair brakes
before raising or lowering
platform.
OPTION
This feature is optional. It may
not be included in all models.
Lift Mechanism (Optional)
Getting on/off the bus is made eas-
ier for the wheelchaired passengers
or passengers with baby stroller.
Lift mechanism can be controlled
from outside the vehicle. Press “Lift
Active Switch” located on left con-
trol panel to activate lift mechanism
control panel.
Operating Lift Mechanism
1.
Switch ignition key on position
“2” and run the engine.
2. Activate parking brake.
3. Ensure the vehicle is steady.
4.
Switch gear into neutral position.
5.
Press “Lift Active Switch” located
on left control panel.
6. Ensure lift door is open.
7.
Control lift mechanism by using
lift mechanism control panel lo-
cated outside of the vehicle.
Power Enable: Provide power to
the pendant and thereby enable
the lift.
Deploy Button: Extand platform
from the lift storage compartment.
Stow Button: Retract the platform
back into the storage compart-
ment.
Down Button: Lower the platform
towards the ground.
Up Button: Raise the platform to
-
wards the vehicle oor.
Button must be held depressed un-
til the motion is completed. Move-
ment of the platform can be halted
at any time by releasing the button.
WARNING
Never try to activate Kneeling-
Lifting function when lifting
mechanism is in use.
3.6 Accessories
INFORMATION
While lift mechanism is oper-
ating;
•
Kneeling-Lifting function is
disabled.
•
Temporary bus stop is acti-
vated. Even parking brake is
released temporary bus stop
prevents moving.
•
Vehicle is prevented to
move until lift is stowed
again into its place.
