Tenda AC11 User Manual

32
Step 4 Connect the upstream device, such as a gateway, to any port of the router.
---End
Log in to the web UI of the router again, and navigate to Status to check if the AP mode is
configured successfully as follows.
If there is another network device with the same login domain name (tendawifi.com) with the router,
log in to the upstream router and find the IP address obtained by the new router in the client list. Then
you can log in to the web UI of the router by visiting the IP address.
To access the internet, connect your computer to physical port, or connect your smart phone to
the WiFi network.
You can find the WiFi name and password on the Wireless Settings > WiFi Name and Password
page. If the network is not encrypted, you can also set a WiFi password on this page for security.

Tenda AC11 Specifications

General

Max WiFi Speed	1200 Mbps
Frequency Bands	2.4 GHz, 5 GHz
RAM	128 MB
MU-MIMO	Yes
WiFi Standard	IEEE 802.11ac
Wireless Standards	IEEE 802.11ac/a/n/g/b
Wireless Speed	300 Mbps (2.4 GHz) + 867 Mbps (5 GHz)
Antennas	5 external antennas
Ports	1 x 10/100Mbps WAN port, 3 x 10/100Mbps LAN ports
Interface	Web-based Interface
Button	WPS/Reset
Security	WPA-PSK/WPA2-PSK
Power Input	100-240V AC, 50/60 Hz
