Tenda AC11 User Manual

78
3. Enter the MAC Address of the host of the FTP server, which is D4:61:DA:1B:CD:89 in this
example.
4. Click .
5. Click OK on the bottom of the page.
----End
When the configurations are completed, users from the internet can access the DMZ host by
visiting “Intranet service application layer protocol name://WAN IP address of the router”. If the
intranet service port number is not the default number, the visiting address should be: “Intranet
service application layer protocol name://WAN IP address of the router:intranet service port
number”.
In this example, the address is “ftp://102.33.66.88”. You can find the WAN IP address of the router
in View system information.
When the default intranet service port number is 80, please change the service port number to an
uncommon one (1024 to 65535), such as 9999.
Enter the user name and password to access the resources on the FTP server.

Tenda AC11 Specifications

General

Max WiFi Speed	1200 Mbps
Frequency Bands	2.4 GHz, 5 GHz
RAM	128 MB
MU-MIMO	Yes
WiFi Standard	IEEE 802.11ac
Wireless Standards	IEEE 802.11ac/a/n/g/b
Wireless Speed	300 Mbps (2.4 GHz) + 867 Mbps (5 GHz)
Antennas	5 external antennas
Ports	1 x 10/100Mbps WAN port, 3 x 10/100Mbps LAN ports
Interface	Web-based Interface
Button	WPS/Reset
Security	WPA-PSK/WPA2-PSK
Power Input	100-240V AC, 50/60 Hz
