Device Management
- 27 -
increase the packet forwarding speed.
Click 『Network』>『Static Route』 to go to the configuration page.
Parameter description in the page:
Manually add a static route.
Current route table information of the router, including default routes and added static
routes.
Destination network address, i.e. IP address where packets reach.
Subnet mask of a destination network address.
Entry IP address of the next-hop route after packets leave from a router port.
Port where packets leave from the router. Select a corresponding WAN port as needed.
Example of static route
Example: An enterprise purchases a G3 enterprise router to establish a network. The Intranet and Internet
are located in different networks. The router has been connected to the Internet through the WAN0 port and
to the Intranet through the WAN1 port. Now, it must be realized that the client under the router needs to
access both the Internet and Intranet. This can be by achieved by setting a static route on the router.
Assume that basic information is as follows:
Intranet information assigned by the company:
