Device Management
- 51 -
Parameter description in the page:
IP group where the rule is valid.
Time when the rule is valid, i.e. time to forbid a client corresponding to an IP group in
the rule from accessing a specified website.
Concurrent session
(one device)
Maximum total number of connections used by every computer in a controlled IP
address range.
Shared: The sum of bandwidths of all IP addresses in a controlled address range is
an uploading/downloading rate set by the current rule.
Exclusive: Every IP address in a controlled address range applies an
uploading/downloading rate set by the current rule.
Uploading/Downloading rate of a client under a corresponding rule. 1 Mbps = 128 KB/s
= 1,024 kb/s
Current status of a rule, including Enabled and Disabled.
Perform the enable/disable, edit, and delete actions on a rule.
Defaults for unlimited
host:
When this item is enabled, the bandwidth parameters of devices excluded from
the list or disabling the rule in the list are "default parameters".
When this item is disabled, only the rule in the list is valid and no bandwidth of
devices excluded from the list or disabling the rule in the list is restricted.
Enabling smart bandwidth control
Click Smart Bandwidth Control and click OK.
Example of custom
Example: An enterprise uses a G3 enterprise router to establish a network. The router LAN port IP address is
192.168.0.252. The subnet mask is 255.255.255.0. Bandwidth control on a client under the router needs to
be set so that the client has a fixed bandwidth. The IP address is 192.168.0.2-192.168.0.100. The time group
restricted for the broadband is 8:00-18:00.
Configuration steps:
Step 1: Set a time group (8:00 - 18:00) as follows. For detailed configuration steps, refer to Steps for adding a time
group.
