58
Appendixes
A.1 Join Your WiFi
A computer can connect to the WiFi network of the router only if it has a wireless network adapter. This
part instructs you how to connect to your wireless network via your notebook or other wireless devices.
We take Windows 8, Windows 7, and Windows XP as examples here.
A.1.1 Windows 8
Step 1 Right-click in the lower-right corner of the desktop.
Step 2 Select the WiFi network of the router from the network list that appears.
Step 3 Enter the WiFi password (network security key) of the WiFi network.
Step 4 Click Next.
---End
If you cannot find the icon, move the cursor to the upper-right corner of the desktop, choose
Settings > Control Panel > Network and Internet > Network and Sharing Center, click Change
adapter settings, right-click WiFi, and choose Disable. Then, right-click WiFi, and choose Enable.
If the WiFi network is not detected, check whether the Airplane mode is enabled.
A.1.2 Windows 7
Step 1 Right-click in the lower-right corner of the desktop.

Table of Contents

Other manuals for Tenda N301

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda N301 and is the answer not in the manual?

Tenda N301 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi bandSingle-band (2.4 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Rack mountingNo
Frequency range2.4 - 2.472 GHz
WLAN data transfer rates supported11, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports3
Security algorithms128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Antennas quantity2
Antenna gain level (max)5 dBi
Product colorWhite
Power source typeDC
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
CertificationFCC, CE, RoH
Cables includedLAN (RJ-45)
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth127.4 mm
Width90.5 mm
Height26 mm
Weight- g
