Tenda O1 User Manual

8
Scenario 2: Peer-to-multiple peers bridging
Step 1 Refer to Peer-to-peer bridging to make any two CPEs bridge to each other.
Step 2 Within 30 minutes after the peer-to-peer bridging succeeds, place the rest CPEs which are
in factory settings near the CPE with the LED1, LED2, and LED3 indicators solid on and
power them on. Wait about 1 minute. When the LED1, LED2, and LED3 indicators of these
new-added CPEs keep blinking, the peer-to-multiple peers bridging succeeds.
CPE 1: AP mode
LED 1, 2 and 3 indicators light
solid on
Client mode
LED 1, 2 and 3 indicators blink
Client mode
LED 1, 2 and 3 indicators blink
CPE 2
CPE 16

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
