Tenda P200 User Manual

P200 200Mbps PowerLine Mini Adapter
6
Chapter 2 Hardware Installation
2.1 Hardware Installation
Method 1:
As seen below: Establishing network for rooms under a single electricity
meter using the Tenda P200 devices requires no extra cable deployment.
Simply plug two P200 devices into the wall outlets in such rooms
respectively and connect 2 PCs to the 2 P200 devices respectively.
Figure 1-3 Establish Powerline Network
Method 2:
As seen below: Rooms A-B are under a single electricity meter. Connect the
first P200 to an ADSL Modem Router in room A using an Ethernet cable, plug
the second P200, connected to a PC, into the wall outlet in room B.

Tenda P200 Specifications

General

Wi-Fi	No
Power plug	-
Ethernet LAN	Yes
Security algorithms	128-bit AES
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	200 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	CE, FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	3 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	27 mm
Width	53 mm
