Tenda P200 User Manual

P200 200Mbps PowerLine Mini Adapter
3
1.3 Interface /Button Overview
Figure2-2 Interface /Button Overview
Interface
/Button
Description
LAN
RJ45 port: Connect it to a PC or other network
devices using an Ethernet cable.
Reset/Pair/Power
Save
System Restore/Pair/Power Save: Pressing the button
twice consecutively within 2 seconds switches the
device to power save mode. Pressing the button once
while in power save mode wakes up the device. Press
for 2-3 seconds to pair with other adapters; press for
9-11 seconds to disconnect from the existing
network; while pressing for over 15 seconds, system
will be restored to factory default settings.
1.4 Features
 Compliant with HomePlugAV IEEE802.3 and IEEE802.3u standards
 Plug and Play; delivers data and power through existing electric wires
 Powerline transmission distance up to 300 meters
 Up to 200Mbps Powerline transmission rate
 QoS prioritizes specified services or applications
 Default network name: HomePlugAV
 Compatible with all other manufacturers’ HomePlugAV-compliant
devices

Tenda P200 Specifications

General

Wi-Fi	No
Power plug	-
Ethernet LAN	Yes
Security algorithms	128-bit AES
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	200 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	CE, FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	3 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	27 mm
Width	53 mm
