Tenda P200 User Manual

P200 200Mbps PowerLine Mini Adapter
15
Chapter 4 Configuration
This section instructs you how to config advanced settings on the P200
utility, such as encryption, changing device name, QoS, and restore factory
defaults, etc. You can also view other adapters on the powerline network
and their link rates.
4.1 Interface Overview
After the utility is installed, double-click the Tenda PowerLine AV Utility
icon on your desktop to start the configuration of the P200. Four
menus are included on the utility as seen below: Adapter, QoS, Tools and
Help. The left area on the Utility displays a list of local Powerline adapters
while the right area shows more info of such adapters.
 HomePlugAV Displays local Powerline network name. Powerline
adapters MUST share an identical network name to establish a
Powerline network. Based on the network name, the Powerline

Tenda P200 Specifications

General

Wi-Fi	No
Power plug	-
Ethernet LAN	Yes
Security algorithms	128-bit AES
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	200 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	CE, FCC
Product color	White
LED indicators	LAN, Power
Sustainability certificates	RoHS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	3 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	27 mm
Width	53 mm
