11N Wireless Broadband Router
(wireless client).
Chapter 7: DHCP Server
7.1 DHCP Settings
DHCP (Dynamic Host Control Protocol) is to assign an IP
address to the computers on the LAN/private network. When
you enable the DHCP Server, the DHCP Server will allocate
automatically an unused IP address from the IP address pool
to the requesting computer in premise of activating “Obtain
an IP Address Automatically”. So specifying the starting and
ending address of the IP Address pool is needed.
DHCP Server:Activate the checkbox to enable DHCP
server.
IP Address Start/End: Enter the range of IP address
for DHCP server distribution.
Lease Time: The length of the IP address lease.
For example
If the lease time is an hour, then DHCP server will reclaim the
38

Table of Contents

Other manuals for Tenda W268R

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda W268R and is the answer not in the manual?

Tenda W268R Specifications

General IconGeneral
VPN supportPPPoE/PPTP/L2TP/802.1x
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity11 channels
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)150 Mbit/s
Bandwidth2.4 GHz
Rack mounting-
xDSL connectionNo
Power requirements9V DC, 1A
Minimum system requirementsInternet Explorer 5.5, Firefox 1.0+ CD-ROM
Ethernet LAN (RJ-45) ports4
Security algorithmsWEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Transmit power0 dBmW
Antenna gain level (max)2 dBi
CertificationFCC, CE, RoHS
AC input voltage100 - 240 V
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Product colorWhite
LED indicatorsLAN, Power, WAN, WLAN
Weight and Dimensions IconWeight and Dimensions
Depth172 mm
Width110.2 mm
Height31 mm
Weight- g
