Tenda W268R User Manual

11N Wireless Broadband Router
6.2 Wireless Security Setting
It is used to configure the AP network’s security setting. Here
presents the common six (ten in all) encryption methods,
including Mixed WEP, WPA-personal, WPA2-personal, etc.
6.2.1 Mixed WEP
WEP (Wired Equivalent Privacy), a basic encryption method,
usually encrypts wireless data using a series of digital keys
(64 bits or 128 bits in length). By using the same keys on
each of your wireless network devices, you can prevent
unauthorized wireless devices from monitoring your
transmissions or using your wireless resources. Select Mixed
WEP to enter the following window:
 Select SSID ： Select the SSID (main SSID or minor
SSID) to configure security setting from the drop-down
menu.
28

Tenda W268R Specifications

General

VPN support	PPPoE/PPTP/L2TP/802.1x
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	11 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Bandwidth	2.4 GHz
Rack mounting	-
xDSL connection	No
Power requirements	9V DC, 1A
Minimum system requirements	Internet Explorer 5.5, Firefox 1.0+ CD-ROM
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Transmit power	0 dBmW
Antenna gain level (max)	2 dBi
Certification	FCC, CE, RoHS
AC input voltage	100 - 240 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Product color	White
LED indicators	LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	172 mm
Width	110.2 mm
Height	31 mm
Weight	- g
