11N Wireless Broadband Router
Rear Panel From L to R：（ ）
POWER
The jack is for power adapter connection. Please use the
included 9V DC power adapter.
WAN
A 100Mbps Ethernet port, can be connected with MODEM,
Switch, Router and other Ethernet device for Internet
connecting to DSL MODEM, Cable MODEM and ISP.
LAN (1, 2, 3, 4)
4 10/100Mbps Ethernet ports can be connected with
Ethernet switch, Ethernet router and NIC card.
RESET
The system reset button. Press this button for 7 seconds,
the settings configured in this device will be deleted and
it will restore the settings to the default one.
WLAN/WPS
WPS button. Press it for 1 second, the WPS feature will
be enabled and WPS indicator will be shown blinking.
6
