4
KEY FEATURES
• 60MHz (or 25MHz) sine wave ouput with 1µHz resolution for full frequency range.
• 25MHz (or 5MHz) impulse waveform with adjustable time rise and fall and duty
cycle.
• 250MSa/s (or 125MSa/s) sample rate and 14-bit vertical resolution.
• 6-digit high precision frequency meter compatible with TTL level signal.
• Standard dual channels with independent channel output mode.
• 1M (or 8k) arbitrary waveform memory and 48 non-volatile waveforms storage.
• Multiple modulation types: AM, FM, PM, ASK, FSK, PSK, PWM.
• Software available for use in PC.
• 4.3” high-resolution TFT colour display.
• Standard interfaces: USB Host, USB Device, optional LAN.
• Dual channels can be applied simultaneously or independently: internal/external
modulation, internal/external/manual trigger.
• Support frequency sweep and burst output.
• Ease-of-use multipurpose knob and numeric keypad.
PRODUCT OVERVIEW
1. USB Port
• The Generator supports USB ash drive in FAT16 and FAT32 format. Through this
USB port, the Generator can read any saved waveforms from USB ash drive or
store current data into the ash drive.
2. On/Off Button
• To power on/off the Generator, press the button; the backlight will illuminate
orange and the Generator will access the power-on interface and then the
functional display.
3. Display Screen
• The Generator features a 4.3” TFT colour display with high-resolution, which
distinguishes output status, menus and other important information between CH1
and CH2 using different colours.
12.Arrow
Buttons
