Tennant 1200 - User Manual

Tennant 1200
44 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
ENGLISH - ESPAÑOL
Portable Carpet Extractor
Extractor Portátil de Alfombras
1200
Operator and Parts Manual
Manual del Operador y Piezas
607302
Rev. 04 (02-04)
Model No.:
611460 - 120V
613736 - 220V
611468 - 230V
CUSTOMER SERVICE:
1–800–982–7658
1–763–513–2850
FAX: 1–800–678–4240
1–763–513–2142
TECHNICAL SUPPORT:
1–800–522–7839 EXT. 5356
TENNANT COMPANY
701 NORTH LILAC DRIVE
MINNEAPOLIS, MN 55422
MAILING ADDRESS:
TENNANT COMPANY
P.O. BOX 1452
MINNEAPOLIS, MN 55440–1452

Table of Contents

Questions and Answers

  • G
    gregoryramirezAug 14, 2025
    What to do if Tennant 1200 has poor solution pick-up?
    • R
      Raymond TaylorAug 14, 2025
      If the Tennant Floor Machine isn't picking up solution effectively, several factors could be at play. A defective recovery tank cover gasket, a clogged float shut-off screen, a loose or missing accessory tool vacuum hose port cover, loose vacuum hose connections or cuffs, or a defective vacuum hose could be the reason. Check and replace the gasket if needed; clean the lint off the screen; check the vacuum hose port cover; secure all vacuum hose connections and cuffs; replace the hose if it is defective. Also, pulling the machine too fast can cause poor pick-up, so slow down your cleaning process.
  • W
    wbellAug 17, 2025
    Why is the brush motor not working on my Tennant 1200 Floor Machine?
    • M
      Monica WaltersAug 17, 2025
      If your Tennant Floor Machine's brush motor isn't working, there could be several reasons. First, make sure you've pulled the brush/solution triggers. If that's not the issue, the brush motor circuit breaker might have tripped. Let the motor cool, and then reset the brush motor breaker button at the rear of the machine.
  • L
    Laura WallaceAug 20, 2025
    What to do if the solution pump does not operate on Tennant Floor Machine?
    • S
      Samantha SmithAug 20, 2025
      If the Tennant Floor Machine solution pump isn't working, start by ensuring you've pulled the brush/solution triggers. If the pump still doesn't operate, the solution pump circuit breaker might have tripped. Allow the pump to cool down, then reset the pump breaker button located at the rear of the machine.
  • W
    whitechristinaAug 25, 2025
    What to do if the Tennant Floor Machine has poor solution pick-up?
    • M
      Mackenzie BurgessAug 25, 2025
      If your Tennant Floor Machine isn't picking up solution effectively, there might be several reasons: * A defective recovery tank cover gasket could be the issue; consider replacing it. * The float shut-off screen might be clogged; open the recovery tank cover and clean off any lint. * Check if the accessory tool vacuum hose port cover is loose or missing. * Make sure all vacuum hose connections are secure under the cover. * A defective vacuum hose could also be the cause, in which case you should replace it. * Ensure vacuum hose cuffs are securely attached to the hose. * Lastly, pulling the machine too fast can affect pick-up, so slow down your cleaning process.
  • C
    Christopher KingAug 27, 2025
    Why my Tennant Floor Machine does not operate?
    • M
      Michael HendersonAug 27, 2025
      If your Tennant Floor Machine isn't turning on, the issue could stem from a tripped building circuit breaker. Try resetting the breaker. If this doesn't solve the problem, the cause may be faulty switches, wiring, or a faulty power cord. In these cases, it is best to contact a service center for assistance.
  • M
    Marcus RhodesAug 31, 2025
    What to do if the brush motor does not operate on my Tennant Floor Machine?
    • K
      Kimberly SaundersAug 31, 2025
      If the brush motor on your Tennant Floor Machine isn't working, here's what you can check: 1. See if the brush motor circuit breaker has tripped. If it has, let the motor cool down, then reset the brush motor breaker button at the rear of the machine. 2. Ensure that you are pulling the brush/solution triggers, as the motor may not operate without this step. For issues such as a loose or broken brush belt, a faulty trigger switch or wiring, or a faulty brush motor, it's recommended to contact a service center.
  • I
    ihoodSep 2, 2025
    How to fix uneven spray on Tennant 1200 Floor Machine?
    • D
      Daniel EnglishSep 3, 2025
      If your Tennant Floor Machine isn't spraying evenly, or not at all, start by checking the solution tank level and refill if low or empty. Plugged or worn spray tips, or using the wrong size or angle, could also be the cause. Clean or replace the tips, or replace them with the correct ones. Also, prime the pump by pressing the solution hose coupler tip located at the front of the machine.
  • D
    Donald RandallSep 6, 2025
    What to do if Tennant 1200 has uneven or no spray?
    • E
      Evelyn HowellSep 6, 2025
      If your Tennant Floor Machine is spraying unevenly or not at all, here are a few things to check: * The spray tips might be plugged; try cleaning or replacing them. * Ensure you're using the proper spray tip size and angle; replace them if necessary. * Check if the solution tank is low or empty and refill it if needed. * If the pump needs priming, prime it by pressing the solution hose coupler tip located at the front of the machine.
  • B
    bwelchSep 9, 2025
    What to do if the solution pump does not operate on my Tennant 1200 Floor Machine?
    • S
      Stanley HudsonSep 9, 2025
      If the solution pump isn't working on your Tennant Floor Machine, start by checking if the solution pump circuit breaker has tripped. If so, let the pump cool down before resetting the pump breaker button located at the rear of the machine. Also, make sure you are pulling the brush/solution triggers. For issues such as a faulty trigger switch/wiring or a faulty solution pump motor, it's recommended to contact a service center.

Summary

Machine Data

Safety Information

SAFETY PRECAUTIONS

Essential safety guidelines for operating the carpet extractor, covering hazards and precautions.

GROUNDING INSTRUCTIONS

Instructions for proper electrical grounding to prevent shock hazards.

SAFETY LABELS

Identification and explanation of warning labels on the machine for safe operation.

Machine Operation and Setup

MACHINE COMPONENTS

Illustration and list of all major parts of the carpet extractor.

MACHINE SETUP

Step-by-step guide for preparing the machine for operation after unpacking.

MACHINE OPERATION

General guidance and procedures for operating the carpet extractor safely and effectively.

PRE-OPERATION

Tasks to perform before starting the machine for cleaning, including checks and setup.

CLEANING CARPETS

Detailed steps for cleaning carpets using the machine's primary functions.

WHILE OPERATING MACHINE

Important considerations and tips for safe and efficient operation during use.

CLEANING WITH ACCESSORY TOOLS

Instructions for using optional accessory tools for specialized cleaning tasks.

Maintenance and Draining

DRAINING RECOVERY TANK

Procedure for emptying the dirty water collection tank.

DRAINING SOLUTION TANK

Steps for emptying the clean water and solution tank.

MACHINE MAINTENANCE

Routine tasks for keeping the machine in good working condition.

DAILY MAINTENANCE

Routine cleaning and checks to perform daily or after 4 hours of use.

WEEKLY MAINTENANCE

Tasks required for weekly upkeep or after 20 hours of operation.

MONTHLY MAINTENANCE

Periodic maintenance procedures for monthly upkeep or after 80 hours of use.

QUARTERLY MAINTENANCE

Maintenance checks to be performed quarterly or after 250 hours of operation.

STORING MACHINE

Proper procedures for storing the machine for extended periods, including winterization.

RECOMMENDED STOCK ITEMS

List of suggested spare parts and supplies for keeping on hand.

Technical Specifications and Troubleshooting

TROUBLE SHOOTING

Guide to diagnosing and resolving common operational problems with the machine.

SPECIFICATIONS

Technical details and performance data for the Tennant 1200 carpet extractor.

MACHINE DIMENSIONS

Diagrams and measurements illustrating the physical size of the machine.

Electrical Diagrams

120 V WIRING DIAGRAM

Detailed wiring diagram for the 120V model of the carpet extractor.

120 V LADDER DIAGRAM

Ladder logic diagram for the 120V electrical system, showing component connections.

220 V;230 V WIRING DIAGRAM

Wiring diagram for the 220V/230V model, detailing electrical component layout.

220 V;230 V LADDER DIAGRAM

Ladder diagram for the 220V/230V model, illustrating circuit flow and connections.

Parts List

SOLUTION TANK GROUP

Illustrated parts breakdown for the solution tank and related components.

RECOVERY TANK GROUP

Illustrated parts breakdown for the recovery tank and associated fittings.

HANDLE GROUP

Illustrated parts list for the machine's handle and trigger assembly.

REAR PANEL GROUP

Illustrated parts breakdown for the rear panel, including switches and connectors.

BRUSH GROUP

Illustrated parts breakdown for the brush motor, brush, and related mounting components.

SOLUTION GROUP

Illustrated parts breakdown for the solution delivery system, including pump and valves.

HAND TOOL

Illustrated parts list for the optional hand tool accessory for upholstery cleaning.

Tennant 1200 Specifications

General IconGeneral
BrandTennant
Model1200
CategoryFloor Machine
LanguageEnglish
