Tennant 550 User Manual (English)

Other manuals for Tennant 550

Questions and Answers:

S
Shane LopezAug 3, 2025
How to improve scrubbing performance of my Tennant Scrubber?
- A
  Ashley WilliamsAug 4, 2025
  If your Tennant Scrubber's performance is lacking, start by checking the scrub brushes for any caught debris and remove it. Ensure that you are using the correct detergent and brushes. Worn scrub brushes should be replaced, and misadjusted brushes should be adjusted. Also, make sure the debris hopper isn't full; if it is, empty it. If the brushes have rotation set, rotate brushes end-for-end. Finally, check the scrub brush drive circuit breaker in case of a scrub brush drive failure.
M
mariacunninghamAug 8, 2025
Why is my Tennant Floor Machine leaving water behind?
- B
  Benjamin ByrdAug 8, 2025
  If your Tennant Floor Machine isn't picking up water effectively, several factors could be the cause. It might be due to a worn or misadjusted rear or side squeegee—try rotating or replacing the rear squeegee blade, adjusting the rear squeegee, or replacing/adjusting the side squeegee. Other potential issues include a clogged vacuum hose (flush it out), a full recovery tank (drain it), a stuck float (clean it), a loose or broken vacuum fan drive belt (adjust or replace it), debris caught on the squeegee (remove it), excessive foam in the recovery tank (empty the tank and reduce detergent), or a disconnected/damaged vacuum hose (reconnect or replace it).
N
Natalie NicholsAug 12, 2025
What to do if Tennant Floor Machine has poor scrubbing performance?
- K
  Kelly WrightAug 12, 2025
  If your Tennant Floor Machine's scrubbing performance is lacking, several issues could be responsible. Check for debris caught on the scrub brushes and remove it. Ensure you're using the correct detergent and brushes. Worn scrub brushes should be replaced, and misadjusted brushes should be adjusted. Also, make sure the debris hopper isn't full (empty it) and that the brushes have the correct rotation (rotate them end-for-end).
A
ariana24Aug 16, 2025
What to do if my Tennant 550 has little or no solution flow?
- K
  kevin09Aug 16, 2025
  If your Tennant Scrubber isn't dispensing enough solution, the first thing to check is whether the solution tank is empty; if so, fill it. If the tank is full, the solution control linkage might be broken or out of adjustment, requiring replacement or adjustment. Another possibility is that the solution supply lines or spreader holes are plugged, in which case you should flush them.
C
Christopher LopezAug 20, 2025
Why Tennant Scrubber motor operates, but there is no pump discharge?
- S
  Sara BrockAug 21, 2025
  If the motor of your Tennant Scrubber is running but there's no pump discharge, it might be due to an unprimed pump. Remove the pump inlet hose, fill the pump chamber with approximately one ounce of SRS solution, and then reinstall the pump inlet hose. The pump should start metering tank solution after 3 to 4 minutes of run time.
L
Logan BrownAug 26, 2025
How to fix little or no solution flow in Tennant Floor Machine?
- B
  Brenda WillisAug 26, 2025
  If your Tennant Floor Machine has little to no solution flow, the issue might stem from several causes. First, ensure the solution tank isn't empty; if it is, fill it. A broken or misadjusted solution control linkage can also be the culprit, in which case you should replace and/or adjust the linkage. Finally, check for plugged solution supply lines or spreader holes, and flush them out as needed.

Tennant 550 Specifications

General

Model	550
Type	Walk-Behind Scrubber
Power Source	Battery
Battery Voltage	24 V
Cleaning Path Width	20 inches
Cleaning Path	20 inches
Brush Pressure	Adjustable
Battery Type	Lead-acid

Summary

MACHINE DATA

GENERAL INFORMATION

SAFETY PRECAUTIONS

Essential safety guidelines and warnings for machine operation and maintenance.

OPERATION

PREPARATION FOR OPERATION

Steps to take after unloading and before operating the machine.

OPERATION OF CONTROLS

MACHINE COMPONENTS

Identification of key parts of the scrubbing machine.

INSTRUMENTS AND CONTROLS

OPERATION

BRAKE PEDAL

Details on the foot brake pedal operation.

DIRECTIONAL PEDAL

Explanation of the machine's propulsion and direction control pedal.

PARKING BRAKE LEVERS

Instructions on using and setting the parking brake.

SCRUB HEAD LOCK LEVER

How to engage and disengage the scrub head lock mechanism.

OPERATION

PIVOT LOCK PIN

Procedure for locking the machine's pivot joint.

MASTER POWER SWITCH

How to operate the main power switch.

CLIMB PUSH BUTTON

Function and use of the climb push button for ramp climbing.

OPERATION

SCRUB BRUSH SWITCH

Control and overload protection for scrub brush motors.

SQUEEGEE SWITCH

Controls rear squeegee position, with override.

SCRUB HEAD POSITION CONTROL LEVER

Adjusting the scrub head lift cylinder position.

OPERATION

SOLUTION CONTROL LEVER

How to control solution flow to the floor.

STEERING WHEEL

Operation and adjustment of the steering wheel.

FUSES AND CIRCUIT BREAKERS

Explanation of circuit protection devices and their locations.

MACHINE OPERATION

NORMAL SCRUBBING OPERATION

Overview of the eight typical steps for scrubbing.

PRE-START CHECKLIST

Essential checks before starting the machine.

TO START MACHINE

Step-by-step instructions to start the machine.

TO FILL SOLUTION TANK

Procedures for safely filling the solution tank.

OPERATION

TO SCRUB

Planning and executing the scrubbing operation.

OPERATION

TO DRAIN AND CLEAN RECOVERY TANK AND EMPTY HOPPER

Steps for draining and cleaning the recovery tank and hopper.

OPERATION

TO STOP MACHINE

Steps required to safely stop the machine.

DOUBLE SCRUBBING OPERATION

When and how to perform double pass scrubbing.

OPERATION ON GRADES

Safe operation practices on inclines and grades.

OPTION OPERATION

VACUUM WAND

Using the vacuum wand attachment for spill cleanup.

TOWING AND TRANSPORTING THE MACHINE

TOWING THE MACHINE

Procedures for safely towing a disabled machine.

TRANSPORTING THE MACHINE

Guidelines for loading and securing the machine for transport.

MACHINE JACKING LOCATIONS

MACHINE STORAGE

STORING MACHINE

Procedures for storing the machine for extended periods.

MAINTENANCE

RECOMMENDED FIRST 50-HOUR MACHINE INSPECTION

Initial inspection procedures after 50 hours of operation.

LUBRICATION

VACUUM FAN SHAFT

Lubrication points for the vacuum fan shaft.

MACHINE PIVOT

Lubrication points for the machine pivot assembly.

MAINTENANCE

SCRUB HEAD PIVOT

Lubrication points for the scrub head pivot assembly.

SCRUB HEAD HINGES

Lubrication points for the scrub head hinges.

REAR SQUEEGEE CASTERS

Lubrication of the rear squeegee casters.

MAINTENANCE

SCRUB BRUSH IDLER PLUGS

Lubrication of the scrub brush idler plugs.

POWER WHEEL

Lubrication and maintenance of the power wheel unit.

HYDRAULICS

HYDRAULIC FLUID

Quality and types of hydraulic fluid used in the machine.

HYDRAULIC FLUID RESERVOIR

Checking and maintaining the hydraulic fluid level.

MAINTENANCE

HYDRAULIC FLUID FILTER

Replacing the hydraulic fluid filter element.

HYDRAULIC FLUID LEAKS

Safety precautions and methods for detecting leaks.

ELECTRICAL SYSTEM

BATTERIES

Maintenance requirements for machine batteries.

MAINTENANCE

BATTERY REPLACEMENT

Information on battery weight and case.

BATTERY CHARGING

Best practices for charging machine batteries.

MAINTENANCE

ELECTRIC MOTORS

Inspection and maintenance of electric motor brushes.

CONTROL PANEL

User-serviceable components of the control panel.

DIRECTIONAL PEDAL

BELTS AND CHAINS

VACUUM FAN DRIVE BELT

Tension and condition check for the vacuum fan drive belt.

PUMP DRIVE BELT

Tension and condition check for the pump drive belt.

SCRUB BRUSH DRIVE CHAINS

Maintenance and tension adjustment for brush drive chains.

SCRUB HEAD

TO ADJUST SCRUB HEAD HEIGHT

Procedure for setting the minimum scrub head height.

MAINTENANCE

TO ADJUST SCRUB BRUSH PATTERN

Method for adjusting brush contact with the floor.

MAINTENANCE

SCRUB BRUSHES

Inspection, rotation, and pattern checking of scrub brushes.

SOLUTION SYSTEM

RECOVERY TANK

Capacity, draining, and cleaning of the recovery tank.

WATER SPRAY DEFLECTOR

Checking the water spray deflector for wear.

MAINTENANCE

SRS WATER SPRAY DEFLECTOR

Checking and installing SRS water spray deflectors.

MAINTENANCE

SRS SOLUTION TANK

Capacity, cleaning, and flushing of the SRS solution tank.

MAINTENANCE

SOLUTION DISPENSING TUBE

Flushing the solution dispensing system.

SRS CLEANING SOLUTION FILTER

Cleaning the filter for cleaning solution.

SRS METERING SOLUTION PUMP

Cleaning and function of the metering pump.

SQUEEGEES

SIDE SQUEEGEES

Maintenance and adjustment of side squeegees.

REAR SQUEEGEE

Maintenance and adjustment of the rear squeegee.

MAINTENANCE

TO REPLACE REAR SQUEEGEE BLADES

Procedure for replacing rear squeegee blades.

TO FACTORY ADJUST REAR SQUEEGEE

Factory adjustment procedure for the rear squeegee.

MAINTENANCE

SQUEEGEE LIFT CYLINDER

Adjustment of the squeegee lift cylinder rod end.

EYEBOLTS

Adjustment of eyebolts for squeegee linkage.

ARM CLEARANCE

Measuring clearance between arm assembly and lift shaft.

MAINTENANCE

TO ADJUST REAR SQUEEGEE

Adjusting rear squeegee rollout, pressure, and tip height.

BRAKES AND TIRES

SERVICE BRAKES

Checking and bleeding the service brake system.

PARKING BRAKES

Adjustment of the parking brake cables.

MAINTENANCE

TIRES

Checking tire pressure and tightening lug nuts.

POWER WHEEL

Lubrication and maintenance of the power wheel.

APPENDIX

HARDWARE INFORMATION

Torque charts and identification for hardware.

APPENDIX

HYDRAULIC FITTING INFORMATION

Torque specifications for hydraulic fittings.

HOW TO USE THIS MANUAL

IMPORTANT INFORMATION

Key information needed when ordering parts.

FINDING A TENNANT PART NUMBER

PLACING AN ORDER

STANDARD PARTS

SRS PARTS

OPTIONS

BREAKDOWNS

CROSS REFERENCE

PART NUMBER TO PAGE NUMBER CROSS REFERENCE LIST

List mapping part numbers to their page references.

PART DESCRIPTION TO PAGE NUMBER CROSS REFERENCE LIST

List mapping part descriptions to their page references.
