Tenney Junior Test Chambers: Models TJR and TUJR, W942, or WF4
Page 10
Read this section completely before attempting to install, or operate the equipment.
5.1 Delivery and Uncrating of Unit
Inspect equipment and shipping crate immediately upon receipt. If any damage is apparent, you should
discuss it with the trucking delivery person and contact the transportation company immediately. Make notes
of any damage on the Bill Of Lading. Retain all shipping materials for inspection. Any claims for damage
must start at the receiving point. Check packing slip carefully and make sure all materials have been
received as indicated on the packing ticket. Unless otherwise noted, YOUR ORDER HAS BEEN SHIPPED
COMPLETE.
Chambers and any remote machinery skids or control cabinets should be handled and
transported in an upright position. They must never be carried on their back, front, or any side.
Important! Inspect the circulation fan inside the chamber. The fan is driven by a motor that is mounted in
isolation bushings. Sometimes during shipping, the motor is pushed out of vertical alignment. If this has
occurred, the fan blade will strike the casing. Eliminate the interference by pushing the motor back into
alignment on its rubber mounts. However, be sure that the shipping abuse was not so great that the
extension shaft on the fan has been bent.
Important! Do to the vibration incurred during shipping and handling, it is possible that mechanical
connections could become loose. Check all connections to make sure they are secure.
5.2 Location and Installation of Unit
Your equipment has been fully operated, tested, and balanced in our plant prior to shipment, unless notified
otherwise. Follow the installation requirements below.
♦ Chamber Weight: Approximately 260 lbs.
♦ Environmental Specifications (For CE European Marked Chambers Only)
Pollution Degree 2, Installation Category III
♦ Do not place the unit near combustible materials or hazardous fumes or vapors.
♦ Ventilation: The chamber should be installed in an area where there is good air ventilation, especially if
an air-cooled condenser is used. Allow a minimum of 18 inches between any wall and chamber side, or
to any equipment mounted to the chamber side.
♦ Do not install unit in a corrosive environment. A corrosive environment may lead to poor performance
and deterioration of unit.
♦ Do not position the chamber in a manner that would make it difficult to operate your main power
disconnect switch. See “Power Connection” below.
♦ Make sure the chamber is leveled when set up.
