TENNEY ENVIRONMENTAL
Tenney Junior Test Chambers: Models TJR and TUJR, W942, or WF4
Page 34
LinkTenn32 is a Microsoft Visual Basic Software application designed for the Microsoft Windows family of
PC Operating Systems. LinkTenn32 utilizes a Multi-Document Interface (MDI) familiar to Windows software
applications so more than one Environmental Chamber Window can be used at a time. LinkTenn32 provides
centralized remote monitoring and control of multiple process controllers simultaneously. LinkTenn32
supports the following controllers: Watlow 942 & F4, Lunaire VersaTenn III, IV, and V Controllers . The
major features provided include:
♦ Interactive remote control and monitoring.
♦ Alarm reporting and notification via Email or Fax.
♦ User-friendly profile program editor.
♦ Logging, printing and graphing of process data.
♦ Exporting of logging history data via an ASCII comma separated values (CSV) file for easy import into
Microsoft Excel or any analysis package that accepts comma separated values (CSV) file format.
The minimum hardware requirements for LinkTenn32 are as follows:
♦ One of these Microsoft Windows PC Operating Systems: Windows 95, 98, 98 Special Edition, NT 4.0
Service Pack 6a, 2000 Service Pack 2
♦ A Pentium Processor 233 MHz or better
♦ 128 MB Ram plus 32 MB for each simultaneous chamber session
♦ 40 MB hard disk space
♦ One serial port
♦ One National Instruments GPIB IEEE Interface (Optional)
♦ One 10/100 Ethernet card using TCP/IP (Optional)
♦ Printer (Optional)
♦ Fax Modem (Optional)
Example Screens:
17.0 LinkTenn32 SOFTWARE (Optional)
-
2 Channel VersaTenn III Screen
LinkTenn32 Sample Graph Screen - 2 Channel
