Tense EM-07K - Device Dimensions; Technical Specifications; Contact Information

20 - Contact
-11-
18 - Technicial Specifications:
%±1
Operating Frequency
Operating Power
Operating Temperature
Voltage Input
Voltage Measurement Range
Current Input
Current Measurement Range
Voltage, Current Accuracy
Supported Connection
Current Transformer Ratio
Voltage Transformer Ratio
Connection Type
Output
Operating Voltage
Cable Diameter
Installation
Operating Altitude
Weight
Protection Class
Panel Hole Size
Communication
85V - 240V AC
50 / 60 Hz
<10VA
-20ºC.....55ºC
5V -300V AC
5V - 300kV
50mA - 5,5A
50mA - 10.000A
3P4W
1....2000
1....999
Plug-in Connection
None
1.5mm²
Front panel mounted
<2000metre
<300Gr.
IP40(Panel), IP00(Body)
91mm x 91mm
RS485 MODBUS RTU
71.5 x 61.5mm Glass LCDDisplay
Merkez Mah. Akalar Sok. No:39A
GAZIOSMANPASA / ISTANBUL / TURKEY
Tel: 0212 578 04 38 - 48 Fax: 0212 578 04 36
Web: Mail: info@tense.com.trwww.tense.com.tr
17- Dimensions:
97,5 mm
96,5 mm
56,75 mm
65 mm
96,5 mm
89,5 mm
12mm
5,08 mm
