Tenways AGO X - Page 9

1
2
Tools needed: No.4 Hex Key
Attention: Only connect cable connectors
of the same color. Connection between
cable connectors of different colors could
potentially damage the bike.
03
Adjust the direction of the headset,
and use the No.4 Hex Key to tighten
the screws at the stem and front fork
(with 5–6 Nm torque).
04
Match the colors of the cable connectors,
and connect the display cables.
01.
INSTALL THE HANDLEBAR
006 Assemble your TENWAYS e-bike
