Tenways CGO800 PLUS - Page 13

Tools needed: No.5 Hex Key
01
Attach the kickstand to the frame with the
No.5 Hex Key (Torque: 9 to 12 Nm).
02
Manually press the button on the back of the
kickstand and adjust the kickstand length
by pushing or pulling the rear section adjust
to the longest setting for best stability.
03
Extend the kickstand to support your e-bike
for the subsequent installation steps.
1
a
b
010
INSTALL THE
KICKSTAND
02.
Install the kickstand
