Tools needed: No.5 Hex Key
01
Adjust the quick release lever to the open
position and install the front wheel onto the
front fork. Make sure that the brake disc is
in the middle of the brake clamps.
02
Tighten the quick release nut. Turn the quick
release lever to the closed position as shown
in the figure.
03
Push the e-bike back and forth and press
the front brake to check if the front wheel
wobbles. If so, please repeat step 2 until
you feel enough resistance when closing
the quick release lever.
04
Turn the front wheel by hand and check if
there are any signs of scraping.
05
If yes, please follow the steps below to
make adjustments:
1. Use the No.5 Hex Key to slightly loosen
the mounting screws of the brake
clamps so that they can move slightly.
2. Press the front brake 3 to 5 times.
3. Hold the front brake and tighten the
mounting screws of the brake clamps.
4. Turn the front wheel by hand and check
for the sound of friction.
5. If you hear friction, loosen the mounting
screws of the brake clamps.
6. Manually adjust the position of the
brake clamps to center the disc, and
tighten the screws again.
Note: This step is very important. Please
follow the instructions carefully.
1
2
a
b
013
INSTALL THE
FRONT WHEEL
05.
Install the front wheel
