You can either charge the battery while it
is installed on the bike or after removing it.
However, it is recommended to remove
the battery and charge it indoors.
01
After placing the bike in a safe location,
you
can charge the battery directly through
the
charging port located on the side of the
battery compartment.
02
To remove the battery, insert the key and
turn it clockwise to unlock the battery,
allowing you to remove it from the bike.
03
Charge the battery with the charger
1. Plug the charger into a
standard power outlet.
Note: The charger is a multi-voltage
unit
and can operate between 100V
and 240V.
2. Lift the small rubber cover on the
battery's charging port.
3. Insert the charger cable into the
charging port.
4. The charger has an LED status indicator:
Green light (when not connected to the
battery) = Ready to charge.
Red light (when connected to the
battery) = Battery is charging.
Green light (when connected to the
battery) = Battery is fully charged.
5. Once charging is complete, disconnect
the charger from the battery.
6.
Unplug the charger from the power outlet
and store it properly.
Note: Ensure the battery charger is
disconnected from the power outlet once
the battery is fully charged or if it's not being
used to charge the battery.
a
b
c
017
CHARGE
THE BATTERY
09.
Charge the battery
