23
Terasic Inc.
D8M-GPIO User Manual
www.terasic.com
September 26, 2018
Quartus project directory: Project directory: DE1_SOC_D8M_RTL
Nios II Eclipse project workspace: Bitstream used: DE1_SOC_D8M_RTL.sof
Demonstration Batch File
Demo batch file folder: demonstrations\ DE1_SOC_D8M_RTL \demo_batch
Demonstration Setup
Connect the DE1-SoC board (J13) to the host PC with a USB cable and
install the USB-Blaster II driver if necessary.
Plug D8M onto DE1-SoC JP2 (GPIO 1), connect VGA monitor to J9 see
Figure 4-2.
Plug the 12V adapter to DE1-SoC Board.
Power on the DE1-SOC board.
Execute the demo batch file “test.bat” from the directory\
DE1_SOC_D8M_RTL\demo_batch.
Below operations are the same with section 4.1 DE1_SoC Line-Buffer Demo.
DE2-115 Demonstration:
Design Tools
Quartus II v15.0
Demonstration Source Code
Quartus project directory: DE2_115_D8M_RTL
Nios II Eclipse project workspace: DE2_115_D8M_RTL.sof
Demonstration Batch File
Demo batch file folder: Demonstrations\ DE2_115_D8M_RTL \demo_batch
Demonstration Setup
Connect the DE2-115 board (J9) to the host PC with a USB cable and install
the USB-Blaster II driver if necessary.
Plug D8M onto DE2-115 JP5 (GPIO), connect VGA monitor to J13 (VGA) see
Figure 4 3.
Plug the 12V adapter to DE2-115 Board.
Power on the DE2-115 board.
Execute the demo batch file “test.bat” from the directory\
DE2_115_D8M_RTL\demo_batch.
Below operations are the same with section 4.1 DE2_115 Line-Buffer Dem
