Terex AL4 - Trailer Wiring Diagram, (ANSI; CSA)

Section 6 • SchematicsAugust 2016
1
2
3
4
5
6
7
8
N M L K J I H G F E D C B A
Part No. 218567 AL4 • AL4000 6 - 13
Trailer Wiring Diagram
(ANSI / CSA models)
BR
WH
GR
MARKER LIGHT
RIGHT FRONT
MARKER LIGHT
LEFT FRONT
MARKER LIGHT
RIGHT REAR
MARKER LIGHT
LEFT REAR
BRAKE LIGHT
RIGHT
BRAKE LIGHT
LEFT
LICENSE PLATE
LIGHT
YL
BL
GR
BR
YL
WH
R
T
G
L
S
BL
GR
BR
YL
WH
12
34
65
WH
BL
YL
GR
BR
7
2
3
4
1
6
5
GR
BR
YL
WH
6-Way
Connector Wiring
4-Way
Connector Wiring
7-Way ‘Blade’
Connector Wiring
7-Way ‘Round Pin’
Connector Wiring
