Terex AL4000D2 Series User Manual

November 2006
Part No. 833002 Rev A AL4000 Light Tower 11
RECEIPT OF DELIVERY CHECKLIST
The tower will be serviced, tested and ready for operation upon delivery. Terex recommends the
following checks:
Insure there is no freight handling damage which should be charged against the carrier.
Make sure the telescoping boom is secure.
Make sure the crosshead assembly is secure.
Check the front and rear jacks for security and proper operation.
Check the outriggers for security and proper operation.
Check that the tires are not damaged, under inflated or that any lugs are loose.
Check the engine/generator for obvious damage, loose connections, or leaks.
Check the control panel for damage or loose connections.
Check the boom wires for obvious damage or loose connections.
Check the light fixtures for damage to the lamps, lenses, reflector or etc.
Check the winches, cables and pulleys for damage and proper operation.
Check the exhaust system for damage.
Check all fluid levels; battery, radiator, and engine oils.
Insure manuals are in the pocket provided inside the unit.

Terex AL4000D2 Series Specifications

General

Rated Output Power	6 kW
Voltage	120/240 V
Frequency	60 Hz
Fuel Type	Diesel
Number of Lamps	4
Lamp Wattage	1000 W
Lamp Type	Metal Halide
Light Output	440, 000 lumens
Fuel Tank Capacity	30 gallons
Lumens per Lamp	110, 000 lumens
Mast Height	30 ft
Mounting Height	30 ft
