November 2006
Part No. 833002 Rev A AL4000 Light Tower 13
SETUP
A. Move the light tower to desired location keeping the following in mind:
1. The light tower should not be placed where those working under the light are either:
a. Forced to look into the light regularly.
b. Forced to work with their backs to the light (shadows will block the light from the
work area).
2. The area where the tower is positioned should be relatively level for safe and proper
operation of the unit.
3. The light tower should be located on the same level or on ground higher than the work
area.
B. Use tire chocks in front of and behind each tire whenever possible. Always use tire
chocks on an incline.
C. Disconnect the towing chain.
D. Unhitch from the towing vehicle as follows:
1. Rotate the tongue jack into position (90 degrees), release the hitch pin and raise the
tongue off the towing vehicle.
E. Level the trailer, using the jacks as follows:
1. Extend the front outriggers until the outrigger pins lock into place. Rotate
the jack on each outrigger into vertical position and lock into place.
2. Rotate the rear jack and lock into the vertical position.
3. Start at the highest jack position. Rotate the jack handle until the jack foot touches the
ground.
4. Raise the other jacks to level trailer.
OUTRIGGERS ARE NOT DESIGNED TO LIFT THE TIRES OFF
THE GROUND.
Insure that all jacks are down to prevent the tower from
tipping over backwards when raised.
NEVER ATTEMPT TO MOVE THE TOWER WHILE THE LEV-
ELLING JACK ARE DOWN. SERIOUS MACHINE DAMAGE
WILL RESULT.
