November 2006

64 AL4000 Light Tower Part No. 833002 Rev A

4” INCH TOWER SECTION

ITEM # PART # DESCRIPTION QTY.

1 124540 4" SECTION 30'TOWER 1

2 109516 KIT:LOCK SLIDE PIN W/ SPRING & SHELL includes 3-9 1

3 990660 ROLL PIN 1/4 X1-5/8 1

4 113362 PIN,LOCK SLIDE,WITH RING includes 10-13 1

5 171635 LOCK PIN SHELL 1

6 171640 LOCK SPRING SHELL 1

7 980340 SCREW,5/16-18NCX1/2 HHCS, GR 2, ZP 1

8 790710 SPRING COIL 1/2 X2.25 1

9 990650 COTTER PIN 1/8X1 SS 1

10 177810 SHIM 3/16X2X19-3/4 1
