November 2006
76 AL4000 Light Tower Part No. 833002 Rev A
RADIATOR MOUNTING BRACKET
ITEM # PART # DESCRIPTION QTY.
1 995380 SCREW, 1/2-13NC X 6-1/2 HHC, GRADE 5, ZP 2
2 990210 WASHER FLAT 1/2 4
3 990415 WASHER, FLAT SNUBBER 2
4 740925 VIBRATION MOUNT, 30 DUR 2
5 740770 VIBRATION MOUNT 35 LB 2
6 124015 ENG.FT/RAD SUPPORT ROADSIDE, D1105/LSA36 (shown) 1
7 124016 ENG.FT/RAD SUPPORT CURBSIDE D1105/LSA36 (not shown) 1
8 124025 ENGINE RISER, 2.75" HIGH FOR 1/2" BOLT 2
9 990200 NUT LOCK NYLON INSERT 1/2-13NC GR 2 ZPIN 2
