November 2006
Part No. 833002 Rev A AL4000 Light Tower 21
11. Relocating light tower to new location:
A. Ensure that tower has been properly lowered (see section 10) and locking pins are
engaged.
B. Ensure all fixtures are pointed toward the ground, or mounted on the fixture storage
brackets on the lower tower section.
C.
All jacks must be raised and all outriggers locked into travel position.
D. Ensure that the coupler is properly secured to the towing vehicle and safety chains are
attached (if supplied). Release any manual braking mechanism (if supplied).
E. Do not tow at excessive speeds (60 mph – 100-kmh maximum) as the weight of the
light tower can cause loss of vehicle control, especially under emergency
stopping conditions. The standard trailer has no towing brakes; therefore
allow extra distance for stopping.
12. Use of light tower auxiliary power:
A. One (1) 30amp/240v Twist-Lock and (1) 20 amp/120v duplex receptacles with GFI are
provided forauxiliary power.
B. Total auxiliary power cannot exceed main circuit breaker rating. Each lamp operating
consumes 9.2 amps @ 120 vac.
C. Before plugging in auxiliary power cords, feed them up through the trailer frame and
attach to receptacles. Close the cabinet doors to protect control panel and
other components from weather (see Miscellaneous Specifications and Routine
Maintenance section for power control details).
OPERATING INSTRUCTIONS
