26 AL4000 Light Tower Part No. 833002 Rev A
TEREX Amida model AL4000 series light tower provides mobile, trailer mounted floodlighting for
nighttime maintenance, construction, mining, and emergency work. It consists of a trailer with a
diesel powered 6 kW 60Hz (50 Hz units available) generator, and a 30 foot cable actuated tower
with four (4) 1000 watt floodlight fixtures. It is ideally suited for heavy-duty use and is built to
meet the following specification:
DIMENSIONS
Overall length, travel position w/fixtures & tongue 179” (4547 mm)
Overall length, tower vertical w/tongue & jacks 124” (3150 mm)
Trailer frame length 70” (1778 mm)
Overall height, floodlighting position 30’ (9114 mm)
Overall height, travel position 68” (1727 mm)
Overall width with fenders 62” (1575 mm)
Overall width with outriggers pulled out 105” (2667 mm)
Trailer frame width 41” (1041 mm)
Tongue length 49” (1245 mm)
Wheel size 15” (381mm)
Axle Rating 3500 lb. (1588 kg)
Tongue weight travel position 100 lb. (45.4 kg)
Total weight no fuel 2050 lb. (930 kg)
Fuel Capacity 30 gal. (114 kg)
Unit weight with full fuel tank 2250 lb. (1020 kg)
Max Highway Speed 60 mph (97 kmh)
NOISE LEVEL
Mean SPL (sound pressure level) hemispherically at 7 meters: 63dBA
Sound Power Level (63 dBA + 20 log d + 7.8): 90.0 LWA re 1 pW
D = 7 meters
DO NOT USE TOWER IN WIND SPEEDS ABOVE 62 MPH (100 KMH).
This section details specifications and maintenance not covered in the operators and trouble-
shooting sections of this manual and the AL4000 specification sheets.
BRAKE SYSTEM
Electrical or mechanical brakes are not standard equipment on the AL4000. Contact your dealer
or the factory for option information.
